TP-Link EAP610-OUTDOOR. Maximum data transfer rate: 1201 Mbit/s, Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n. Security algorithms: WEP, WPA, WPA2, WPA3. Management protocols: SNMP v1/v2c. Management platform: Omada. AC input voltage: 8 V, Input current: 0.5 A
| 2.4 GHz |
Y |
| 5 GHz |
Y |
| 6 GHz |
N |
| Maximum data transfer rate |
1201 |
| Ethernet LAN data rates |
10,100,1000 |
| Networking standards |
IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n |
| Automatic channel selection |
Y |
| Automatic channel scanning |
Y |
| MIMO |
Y |
| MIMO type |
Multi User MIMO |
| Wi-Fi Multimedia (WMM)/(WME) |
Y |
| VLAN support |
Y |
| Rate limiting |
Y |
| Wireless isolation |
Y |
| Band steering |
Y |
| Quality of Service (QoS) support |
Y |
| BeamForming |
Y |
| Security algorithms |
WEP,WPA,WPA2,WPA3 |
| MAC address filtering |
Y |
| Number of SSID supported |
16 |
| Remote Authentication Dial-In User Service (RADIUS) |
Y |
| Management protocols |
SNMP v1/v2c |
| Web-based management |
Y |
| Syslog |
Y |
| Management platform |
Omada |
| Ethernet LAN (RJ-45) ports |
1 |
| Power over Ethernet (PoE) |
Y |
| AC input voltage |
8 |
| Input current |
0.5 |
| Placement |
Pole,Wall |
| Product colour |
White |
| International Protection (IP) code |
IP67 |
| LED indicators |
Y |
| Antenna type |
Internal |
| Antenna features |
Integrated antenna |
| Antenna gain level (max) |
5 |
| Width |
280.4 |
| Depth |
106.5 |
| Height |
56.9 |
| Package width |
241 |
| Package depth |
325 |
| Package height |
67 |
| Package weight |
1290 |
| Number of products included |
1 |
| PoE adapter included |
Y |
| Mounting kit |
Y |
| Operating relative humidity (H-H) |
10 - 90 |
| Operating temperature (T-T) |
-30 - 70 |
| Storage temperature (T-T) |
-40 - 70 |
| Storage relative humidity (H-H) |
5 - 90 |
| Harmonized System (HS) code |
85176990 |
