TP-Link TL-SG1005D. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 5. Full duplex. MAC address table: 8000 entries, Switching capacity: 10 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x. Power connector: DC-in jack
| Switch type |
Unmanaged |
| Basic switching RJ-45 Ethernet ports quantity |
5 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity |
5 |
| Power connector |
DC-in jack |
| Networking standards |
IEEE 802.3,IEEE 802.3ab,IEEE 802.3u,IEEE 802.3x |
| Full duplex |
Y |
| Half duplex |
Y |
| Flow control support |
Y |
| Auto MDI/MDI-X |
Y |
| Auto-negotiation |
Y |
| MAC address auto-learning supported |
Y |
| MAC address auto-aging supported |
Y |
| Supported data transfer rates |
10/100/1000 Mbit/s |
| Switching capacity |
10 |
| MAC address table |
8000 |
| Store-and-forward |
Y |
| Maximum data transfer rate |
1 |
| Jumbo frames support |
Y |
| Jumbo frames |
15000 |
| Rack mounting |
N |
| Product colour |
Black |
| LED indicators |
Y |
| Power source |
DC |
| Input current |
0.6 |
| Input voltage |
9 |
| Power consumption (max) |
2.41 |
| Power over Ethernet (PoE) |
N |
| Operating temperature (T-T) |
0 - 40 |
| Storage temperature (T-T) |
-40 - 70 |
| Operating relative humidity (H-H) |
10 - 90 |
| Storage relative humidity (H-H) |
5 - 90 |
| Heat dissipation |
8.22 |
| Width |
165 |
| Depth |
108 |
| Height |
28 |
| Quick start guide |
Y |
| Package width |
145 |
| Package depth |
108 |
| Package height |
85 |
| Package weight |
240 |
