TP-Link TL-SG1005LP. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 5. MAC address table: 2000 entries, Switching capacity: 10 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x. DC input voltage: 53.5 V. Power over Ethernet (PoE). Wall mountable
| Switch type |
Unmanaged |
| Quality of Service (QoS) support |
Y |
| Basic switching RJ-45 Ethernet ports quantity |
5 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity |
5 |
| Networking standards |
IEEE 802.1p,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x |
| 10G support |
N |
| Copper ethernet cabling technology |
10BASE-T,100BASE-TX,1000BASE-T |
| Cable types supported |
Cat3,Cat4,Cat5,Cat5e,Cat6 |
| Flow control support |
Y |
| Auto MDI/MDI-X |
Y |
| Auto-negotiation |
Y |
| MAC address auto-learning supported |
Y |
| MAC address auto-aging supported |
Y |
| Switching capacity |
10 |
| Forwarding rate |
7.44 |
| MAC address table |
2000 |
| Store-and-forward |
Y |
| Jumbo frames support |
Y |
| Jumbo frames |
16000 |
| IGMP snooping |
Y |
| Rack mounting |
N |
| Stackable |
N |
| Product colour |
Black |
| LED indicators |
Y |
| Wall mountable |
Y |
| Certification |
FCC, CE, RoHS |
| Maximum cable length |
100 |
| Fanless |
Y |
| Power source |
DC/PoE |
| Power supply included |
Y |
| AC input voltage |
100 - 240 |
| AC input frequency |
50/60 |
| DC input voltage |
53.5 |
| Input current |
0.81 |
| Power consumption (max) |
47.5 |
| Power over Ethernet (PoE) |
Y |
| Power over Ethernet plus (PoE+) ports quantity |
4 |
| Total Power over Ethernet (PoE) budget |
40 |
| Operating temperature (T-T) |
0 - 40 |
| Storage temperature (T-T) |
-40 - 70 |
| Operating relative humidity (H-H) |
10 - 90 |
| Storage relative humidity (H-H) |
5 - 90 |
| Heat dissipation |
161.98 |
| Width |
99.8 |
| Depth |
98 |
| Height |
25 |
| User guide |
Y |
| Package type |
Box |
| Package width |
131 |
| Package depth |
196 |
| Package height |
121 |
| Package weight |
730 |
| Sustainability compliance |
Y |
| Sustainability certificates |
CE,Federal Communications Commission (FCC),RoHS |
| Harmonized System (HS) code |
85176990 |
