TP-Link TL-WR840N. WAN connection type: RJ-45. Wi-Fi band: Single-band (2.4 GHz), Top Wi-Fi standard: Wi-Fi 4 (802.11n), WLAN data transfer rate (max): 300 Mbit/s. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Cabling technology: 10/100Base-T(X). Security algorithms: WEP, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise, Firewall security: SPI. Supported network protocols: IPv4, IPv6
| Ethernet WAN |
Y |
| DSL WAN |
N |
| SIM card slot |
N |
| 3G/4G USB modem compatibility |
N |
| WAN connection type |
RJ-45 |
| Wi-Fi band |
Single-band (2.4 GHz) |
| Top Wi-Fi standard |
Wi-Fi 4 (802.11n) |
| WLAN data transfer rate (max) |
300 |
| Wi-Fi standards |
802.11b,802.11g,Wi-Fi 4 (802.11n) |
| Ethernet LAN |
Y |
| Ethernet LAN interface type |
Fast Ethernet |
| Ethernet LAN data rates |
10,100 |
| Cabling technology |
10/100Base-T(X) |
| Networking standards |
IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.3,IEEE 802.3u |
| Port forwarding |
Y |
| Port triggering |
Y |
| Number of guest networks (2.4 GHz) |
1 |
| VPN support |
PPTP, L2TP, IPSec |
| Receiver sensitivity |
270M: -68dBm@10% PER
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER |
| Ethernet LAN (RJ-45) ports |
4 |
| USB port |
N |
| DC-in jack |
Y |
| Web-based management |
Y |
| Quality of Service (QoS) support |
Y |
| Reset button |
Y |
| WPS push button |
Y |
| Security algorithms |
WEP,WPA,WPA-Enterprise,WPA2,WPA2-Enterprise |
| Firewall |
Y |
| Firewall security |
SPI |
| Guest access |
Y |
| Filtering |
Y |
| MAC address filtering |
Y |
| URL filtering |
Y |
| DMZ support |
Y |
| DHCP client |
Y |
| DHCP server |
Y |
| Universal Plug and Play (UPnP) |
Y |
| Supported network protocols |
IPv4, IPv6 |
| Product colour |
Grey,White |
| LED indicators |
Y |
| On/off switch |
Y |
| Product type |
Tabletop router |
| Sustainability compliance |
Y |
| Sustainability certificates |
RoHS,Federal Communications Commission (FCC),CE |
| Cables included |
LAN (RJ-45) |
| AC adapter included |
Y |
| Quick installation guide |
Y |
| Antenna design |
External |
| Antenna gain level (max) |
5 |
| Antennas quantity |
2 |
| Built-in processor |
Y |
| Processor cores |
1 |
| Power source type |
DC |
| Output voltage |
9 |
| Output current |
0.6 |
| Operating temperature (T-T) |
0 - 40 |
| Storage temperature (T-T) |
-40 - 70 |
| Operating relative humidity (H-H) |
10 - 90 |
| Storage relative humidity (H-H) |
5 - 90 |
| Windows operating systems supported |
Windows 2000,Windows 2000 Professional,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows Vista Business,Windows Vista Business x64,Windows Vista Enterprise,Windows Vista Enterprise x64,Windows Vista Home Basic,Windows Vista Home Basic x64,Windows Vista Home Premium,Windows Vista Home Premium x64,Windows Vista Ultimate,Windows Vista Ultimate x64,Windows XP Home,Windows XP Home x64,Windows XP Professional,Windows XP Professional x64 |
| Linux operating systems supported |
Y |
| Mac operating systems supported |
Y |
| Width |
182 |
| Depth |
128 |
| Height |
35 |
| Package width |
265 |
| Package depth |
180 |
| Package height |
86 |
| Package weight |
430 |
| WLAN data transfer rates supported |
11,54,300 |
