People & Vehicle Analytics
Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier.

Human & Vehicle Classification
Distinguish humans and vehicles from other objects and receive more accurate event notifications.

Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.

Type	IP security camera
Placement supported	Outdoor
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Day/night mode	Yes
Infrared (IR) cut-off filter	Yes
Built-in light	Yes
Dynamic range	120 dB
Certification	CE, NTRA, VCCI, KC, BSMI, FCC, IC
Form factor	Bullet
Mounting type	Wall
Product colour	White
Housing material	Metal
International Protection (IP) code	IP67
Minimum illumination	0.005 lx
Angle of rotation	360°
Lens viewing angle, horizontal	80.4°
Lens viewing angle, vertical	41.8°
Lens viewing angle, diagonal	98.7°
Tilt angle range	0 - 90°
Pan range	0 - 360°
Camera shutter speed	1/3 to 1/10000 s
Number of Privacy masking areas	4
Optical sensor size	25.4 / 2.7 mm (1 / 2.7")
Progressive scan	Yes
Sensor type	CMOS
Number of lenses	1
Detect distance	80 m
Observe distance	33 m
Recognize distance	16 m
Maximum aperture number	1.6
Identify distance	8 m
Fixed focal length	4 mm
Night vision	Yes
Night vision distance	30 m
LED type	IR/White
Number of illumination LEDs	2
Infra-red wavelength	850 nm
Maximum resolution	2688 x 1520 pixels
Total megapixels	4 MP
Video compression formats	H.264, H.264+, H.265, H.265+
Supported graphics resolutions	1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440
Frame rate	30 fps
Noise reduction	Yes
Noise reduction technology	3D noise reduction
Privacy masking	Yes
Bit rate control	Constant Bit Rate (CBR), Variable Bit Rate (VBR)
Back Light Compensation (BLC)	Yes
Highlight Compensation (HLC)	Yes
Region of Interest (ROI) encoding	Yes
Smart IR	Yes
Built-in speaker(s)	Yes
Audio system	2-way
Signal-to-Noise Ratio (SNR)	52 dB
Built-in microphone	Yes
Ethernet LAN	Yes
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
Wi-Fi	No
Bluetooth	No
Live view	Yes
Built-in HDD	No
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	512 GB
Ethernet LAN (RJ-45) ports	1
DC-in jack	Yes
Password protection	Yes
Video motion detection	Yes
IP address filtering	Yes
Mirror	Yes
Human and vehicle targets classification	Yes
Digest authentication	Yes
Reset button	Yes
Power source type	DC, PoE
Power consumption (max)	9.7 W
Power consumption (Power over Ethernet (PoE))	10.7 W
DC output voltage	12
Operating temperature (T-T)	-30 - 60 °C
Storage temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Width	184 mm
Depth	74 mm
Height	74 mm
Weight	525 g
Number of cameras	1
