People & Vehicle Analytics
Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier.

Human & Vehicle Classification
Distinguish humans and vehicles from other objects and receive more accurate event notifications.

Smart Video Enhancement Technology

- True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.△

- Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.
- 3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.
- White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.

Type	IP security camera
Placement supported	Outdoor
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Day/night mode	Yes
Infrared (IR) cut-off filter	Yes
Dynamic range	120 dB
Form factor	Bullet
Mounting type	Wall
Product colour	White
Housing material	Metal, Plastic
International Protection (IP) code	IP67
Camera pan control	Yes
Camera tilt control	Yes
Minimum illumination	0.0005 lx
Lens viewing angle, horizontal	88°
Lens viewing angle, vertical	46°
Lens viewing angle, diagonal	105.4°
Tilt angle range	-90 - 90°
Pan range	0 - 360°
Camera shutter speed	1/10000 s
Number of Privacy masking areas	4
Optical sensor size	25.4 / 1.2 mm (1 / 1.2")
Sensor type	CMOS
Number of lenses	1
Detect distance	80 m
Observe distance	33 m
Recognize distance	16 m
Lens diameter	4 mm
Focal length range	4 mm
Maximum aperture number	1.6
Identify distance	8 m
Minimum aperture number	1.6
Fixed focal length	4 mm
Night vision	Yes
Night vision distance	30 m
LED type	IR/White
Number of illumination LEDs	4
Infra-red wavelength	850 nm
Maximum resolution	2880 x 1620 pixels
Total megapixels	5 MP
Video compression formats	H.264, H.264+, H.265, H.265+
Supported graphics resolutions	1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2688 x 1520, 2880 x 1620
Frame rate	60 fps
Noise reduction	Yes
Noise reduction technology	3D noise reduction
Bit rate control	Constant Bit Rate (CBR), Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Bit rate	6 Mbps
Region of Interest (ROI) encoding	Yes
Smart IR	Yes
Built-in speaker(s)	Yes
Sample rate	8 kHz
Signal-to-Noise Ratio (SNR)	52 dB
Built-in microphone	Yes
Bit rate range	256 - 6000 Kbit/s
Ethernet LAN	Yes
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
Ethernet LAN (RJ-45) ports	1
DC-in jack	Yes
Password protection	Yes
IP address filtering	Yes
Privacy protection	Yes
Digest authentication	Yes
Power source type	DC, PoE
Power consumption (max)	10.1 W
Operating temperature (T-T)	-30 - 60 °C
Storage temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Width	184 mm
Depth	74 mm
Height	74 mm
Weight	525 g
Number of cameras	1
